LFDPR Series
The Low Flow with DP Regulator is a reliable flow measurement device suitable for various industrial applications. It features a borosilicate glass tube with a measuring span of 1:10, making it ideal for precise flow control. Designed for online installation, it accommodates center-to-center distances from 100 mm to 300 mm. The flow range spans from 260 NLPH to 5000 NLPH for air and 6 LPH to 160 LPH for water. Constructed from durable materials such as MS, SS304, SS316, or brass, it offers flexibility in application. The connections are 1/4 BSP/NPT (F), with configurations available in back-to-back or bottom-to-top. A clear acrylic cover ensures visibility from three sides, while the linear scale provides simple reading. With an accuracy of ±5% of the full scale, the device is easy to maintain, features replaceable components, and comes with a powder-coated finish for enhanced durability and resistance to corrosion.
Technical Specifications
| Glass | Borosilicate |
|---|---|
| Center to Center Distance | 100 mm to 300 mm |
| Flow Range | Aair: 260 NLPH – 5000 NLPH \nWater: 6 LPH – 160 LPH |
| Various Materials of Constructions | MS/SS304/SS316/Brass |
| Connections | 1/4 BSP/NPT (F) Back – Back/Bottom – Top |
| Accuracy | +/- 5% of Full-Scale |
| Measuring Span | 1:10 |
| Scale | Linear |
